Sign-off
Verification Platform
Providing sign-off solutions covering PV, RCx, STA, and power analysis
Sign-off Verification Platform
Huaxin Sign-off Verification Platform delivers solutions including physical verification, parasitic extraction, static timing analysis (STA), and power analysis with great correlation with sign-off tools:
• The hierarchical and distributed architecture enables fast design error detection, significantly reducing development cycles
• Built-in distributed EM solver supports advanced-node physical effects modeling
• Multi-corner multi-mode analysis with Elmore/Arnoldi wire delay and NLDM/CCS cell delay models delivers high-reliability STA results
• Comprehensive power analysis: dynamic/leakage power, IR drop, and EM analysis
• Interactive visualization for rapid violation debugging
DRC
Design Rule Checking
Hierarchical and distributed processing accelerates DRC closure
LVS
Layout Versus Schematic
High-speed LVS consistency checking via scalable hierarchical and distributed computing
RCX
RC Extraction
Distributed EM solver enables advanced-node ready physical effects modeling and high-accuracy parasitic extraction
Timing
Static Timing Analysis
Delivers signoff-quality STA through multi-corner multi-mode (MCMM) analysis and advanced computational models
Power
Power Analysis
Supports power analysis, IR drop analysis, and EM analysis
Key Features and Benefits
Quick DRC convergence with Smart DRC repair algorithms
Support for multi-corner analysis and point-to-point parasitic extraction and delay calculation
Advanced statistical static timing analysis
Visualization for power analysis, IR drop analysis, and EM analysis
